LT1785AIS8#TRPBF

The LT1785AIS8#TRPBF is an integrated circuit (IC) transceiver manufactured by Analog Devices Inc. (ADI), also known as Maxim Integrated. This device is specifically designed for RS422 and RS485 communication protocols, providing a half-duplex transceiver function.

Key Features and Specifications:

1. Protocol Support:
   • Supports both RS422 and RS485 communication protocols.
2. Transceiver Type:
   • Half-duplex transceiver, allowing for communication in one direction at a time.
3. Driver/Receiver Configuration:
   • Features one driver and one receiver.
4. Voltage Range:
   • Operates within a supply voltage range of 4.75V to 5.25V.
5. Data Rate:
   • Supports a data rate of up to 250kbps.
6. Temperature Range:
   • Designed to operate within a temperature range of -40°C to 85°C.
7. Package Type:
   • Packaged in an 8-SOIC (small outline integrated circuit) package, which is compact and suitable for surface mount technology (SMT) assembly.
8. Receiver Hysteresis:
   • The receiver has a hysteresis of 20mV, which helps to improve noise immunity and stability.
9. Interface:
   • Designed for differential bus communication, supporting up to 128 nodes on the bus.
10. Applications:
    • Ideal for use in industrial, automation, and communication systems requiring reliable RS422 or RS485 communication.

Additional Notes:

• The LT1785AIS8#TRPBF is part of ADI’s extensive portfolio of interface ICs, which offers a wide range of solutions for different communication protocols and applications.
• With its compact packaging, wide operating range, and support for both RS422 and RS485 protocols, the LT1785AIS8#TRPBF is an excellent choice for applications requiring reliable and efficient communication over differential buses.
• The device is also known for its high-performance and low-power consumption, making it suitable for use in battery-powered devices and systems requiring energy efficiency.

In summary, the LT1785AIS8#TRPBF is a high-performance half-duplex transceiver IC designed for RS422 and RS485 communication protocols. Its compact packaging, wide operating range, and support for up to 128 nodes on the bus make it an ideal choice for a wide range of industrial, automation, and communication applications.
