ADA4841-2YRZ-R7

The AD8226BRZ-R7 is a high-performance, wide supply range, rail-to-rail output instrumentation amplifier manufactured by Analog Devices Inc. (ADI). This amplifier offers exceptional precision and stability, making it ideal for a wide range of applications including measurement and control systems, data acquisition systems, and other critical instrumentation circuits.

Key Features:

1. Wide Supply Range:
   • The AD8226BRZ-R7 operates over a wide supply voltage range, from 2.2V to 36V, providing flexibility in various power supply environments.
2. Rail-to-Rail Output:
   • The amplifier features rail-to-rail output capabilities, enabling it to produce output signals that span the entire supply voltage range. This allows for maximum signal utilization and dynamic range.
3. Low Input Bias Current:
   • With an input bias current of only 20nA, the AD8226BRZ-R7 minimizes errors due to input currents, making it suitable for high-impedance sources.
4. Low Input Offset Voltage:
   • The amplifier has a low input offset voltage of 50uV, ensuring high accuracy in measurement and control applications.
5. High Gain Bandwidth Product:
   • The AD8226BRZ-R7 offers a high gain bandwidth product (GBP), which allows it to maintain high gain while supporting high-frequency signals.
6. High Common-Mode Rejection Ratio (CMRR):
   • With a CMRR of 105dB, the amplifier effectively rejects common-mode signals, enhancing the signal-to-noise ratio and improving the overall performance of the instrumentation circuit.
7. Compact Package:
   • The AD8226BRZ-R7 is available in a compact SOIC-8 package, making it suitable for use in space-constrained applications.
8. Operating Temperature Range:
   • The amplifier operates over a wide temperature range of -40°C to +125°C, ensuring reliability in diverse environmental conditions.

Applications:

• Measurement and control systems
• Data acquisition systems
• Instrumentation circuits
• Medical equipment
• Test and measurement equipment

In summary, the AD8226BRZ-R7 is a versatile and high-performance instrumentation amplifier that offers a combination of precision, stability, and flexibility. Its wide supply range, rail-to-rail output, and low input bias current make it suitable for a wide range of applications, ensuring high accuracy and reliability in critical instrumentation circuits.
