ULN2804ADTR

Manufacturer Part Number: ULN2804ADTR Manufacturer / Brand: XBLW
Part of Description: The MIC29302DTR is a high-current, high-accuracy, low-dropout voltage regulator designed for use in a wide range of electronic applications. Lead Free Status / RoHS Status: Digital Signal Processors & Controllers - DSP, DSC 16 BIT HYBRID CNTRLR
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS
Datasheets:

Product parameters

ManufacturerXBLW
DetailsRoHS
Mounting StyleSMD/SMT
Package / CaseSOP-18
Minimum Operating Temperature– 40 C
Transistor Polarity+85 C
PackagingTape
Moisture SensitiveYes
Factory Pack Quantity2500

Get in touch with us now

    Please submit your BOM List or Input the part online

    Please complete all required fields with your contact information.Click "SUBMIT REQUEST" we will contact you shortly by email. Or Email us: Sales001@easyiee.com

    First name *

    Last name *

    Company Email *

    Phone number *

    Company name *

    Country *

    Upload file: We support .xls, .xlsx and .csv files under 4MB

    CHOOSE FILE

    Please submit your BOM List or Input the part online

    SUBMIT INFORMATION

    The ULN2804ADTR is a high-voltage, high-current Darlington transistor array IC manufactured by a leading semiconductor company, often associated with brands like Allegro or STMicroelectronics. Here is a detailed description of the ULN2804ADTR in English:

    The ULN2804ADTR comprises eight Darlington transistors with a common emitter, specifically designed for driving inductive loads. Each Darlington transistor features a peak load current rating of 600mA (with 500mA continuous), and can withstand at least 50V in the off-state. The outputs can be paralleled to achieve higher current capabilities.

    Key Features:

    1. Eight Darlington Transistors:
      • The IC contains eight independent Darlington transistors, each providing high current gain and voltage amplification.
    2. High-Voltage, High-Current Capability:
      • With a maximum collector-emitter voltage of 50V and a peak load current rating of 600mA, the ULN2804ADTR is suitable for driving a wide range of power loads.
    3. Integrated Suppressor Diodes:
      • Each output channel incorporates an integrated suppressor diode, which protects the IC from transient voltage spikes generated by inductive loads during switching.
    4. CMOS-Compatible Inputs:
      • The IC has CMOS-compatible inputs with an input resistance of 10.5kΩ, allowing it to interface easily with digital circuits and microcontrollers.
    5. Convenient Pin Configuration:
      • The ULN2804ADTR adopts an 18-pin plastic DIP package with convenient input and reverse output pins, simplifying circuit board layout.
    6. Wide Operating Voltage Range:
      • The IC can operate within a wide power supply voltage range, typically between 4V and 30V.
    7. Multi-Channel Driver:
      • The ULN2804ADTR serves as a multi-channel driver, integrating eight independent high-current, high-voltage switch outputs. Each channel can drive different loads.
    8. Current Amplification:
      • It has the ability to amplify input signal current, enabling the control of loads requiring higher currents.
    9. ESD Protection:
      • The IC includes electrostatic discharge (ESD) protection to enhance reliability in ESD environments.
    10. Small Package:
      • Offered in a small package, it is easy to integrate onto circuit boards.

    Typical Applications:

    • Relay Drivers: The ULN2804ADTR can drive relays, controlling the switching of high-voltage circuits.
    • Stepper Motor Drivers: Suitable for driving stepper motors in automation and robotics applications.
    • Lamp and Bulb Drivers: Capable of controlling incandescent lamps, LEDs, and other lighting devices.
    • Electromagnetic Valves: Can be used to control electromagnetic valves in industrial and automotive applications.
    • Display Drivers: Suitable for driving displays, such as segment displays and small LED arrays.

    In summary, the ULN2804ADTR is a powerful high-current driver IC designed for applications requiring the control and driving of high-current loads. Its multi-channel design and internal protection features make it a common choice in many electronic designs, particularly in embedded systems.
