TLE5205-2G

Manufacturer Part Number: TLE5205-2G Manufacturer / Brand: Infineon
Part of Description: Motor / Motion / Ignition Controllers & Drivers 5-A H-Bridge for DC-Motor App 40V Lead Free Status / RoHS Status: table_img Lead free / RoHS Compliant
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS
Datasheets:

Product parameters

ManufacturerInfineon
RoHSDetails
Mounting StyleSMD/SMT
Package / CaseTO-263-7
Output Current5 A
Operating Supply Current10 mA
PackagingReel
Minimum Operating Temperature– 40 C
Maximum Operating Temperature+ 150 C
Factory Pack Quantity1000
SubcategoryPMIC – Power Management ICs
Part # AliasesTLE5252GXT SP000377307 TLE52052GAUMA1
Unit Weight0.075432 oz
