STM32L431RCT6

Manufacturer Part Number: STM32L431RCT6 Manufacturer / Brand: ST
Part of Description: ARM Microcontrollers - MCU 32B ARM Cortex-M4 2Mb Flash 168MHz CPU Lead Free Status / RoHS Status: table_img Lead free / RoHS Compliant
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS
Datasheets:

Product parameters

ManufacturerST
RoHSDetails
Mounting StyleSMD/SMT
Package / CaseLQFP-64
Program Memory Size256 kB
CoreARM Cortex M4
Data Bus Width32 bit
Minimum Operating Temperature– 40 C
Maximum Operating Temperature+ 85 C
PackagingTray
Factory Pack Quantity960
SubcategoryMicrocontrollers – MCU
Watchdog TimersWatchdog Timer, Windowed
Unit Weight0.012335 oz

Get in touch with us now

    Please submit your BOM List or Input the part online

    Please complete all required fields with your contact information.Click "SUBMIT REQUEST" we will contact you shortly by email. Or Email us: Sales001@easyiee.com

    First name *

    Last name *

    Company Email *

    Phone number *

    Company name *

    Country *

    Upload file: We support .xls, .xlsx and .csv files under 4MB

    CHOOSE FILE

    Please submit your BOM List or Input the part online

    SUBMIT INFORMATION

    The STM32L431RCT6 is a microcontroller from STMicroelectronics’ STM32L4 series, designed for ultra-low-power applications. Here’s a detailed description:
    • Core: ARM Cortex-M4 with FPU (Floating Point Unit), operating at up to 80 MHz.
    • Flash Memory: 256 KB of Flash memory for program storage.
    • RAM: 64 KB of SRAM for data storage.
    • I/O Ports: Up to 51 General-Purpose I/O (GPIO) pins.
    • Timers: Includes multiple timers, such as 16-bit and 32-bit general-purpose timers, a low-power timer, and watchdog timers.
    • Communication Interfaces: Provides a wide range of communication interfaces, including USART, SPI, I2C, CAN, and USB.
    • Analog Features: Features a 12-bit ADC (Analog-to-Digital Converter) with up to 16 channels, 12-bit DAC (Digital-to-Analog Converter), and multiple analog comparators.
    • Operating Voltage: 1.71V to 3.6V, supporting battery-operated and low-power applications.
    • Low-Power Modes: Multiple low-power modes, including Stop and Standby, to minimize power consumption.
    • Package: Available in a 64-pin LQFP (Low-Profile Quad Flat Package).
    • Peripherals: Includes a real-time clock (RTC), temperature sensor, and several other peripherals for various applications.

    The STM32L431RCT6 is ideal for applications requiring high performance with low power consumption, such as wearable devices, medical instrumentation, and energy-efficient industrial controls.
