STM32F427ZGT6

Manufacturer Part Number: STM32F427ZGT6 Manufacturer / Brand: ST
Part of Description: ARM Microcontrollers - MCU 32B ARM Cortex-M4 1Mb Flash 168MHz CPU Lead Free Status / RoHS Status: 16-bit Microcontrollers - MCU MCU 3/5V 56K Pb-free 64-QFP
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS
Datasheets:

Product parameters

ManufacturerST
DetailsRoHS
Mounting StyleSMD/SMT
Package / CaseLQFP-144
Minimum Operating Temperature– 40 C
Maximum Operating Temperature+85 C
PackagingTray
Moisture SensitiveYes
Program Memory TypeFlash
Factory Pack Quantity360
SubcategoryMicrocontrollers – MCU
TradenameSTM32
Watchdog TimersWatchdog Timer
Unit Weight0.045518 oz

Get in touch with us now

    Please submit your BOM List or Input the part online

    Please complete all required fields with your contact information.Click "SUBMIT REQUEST" we will contact you shortly by email. Or Email us: Sales001@easyiee.com

    First name *

    Last name *

    Company Email *

    Phone number *

    Company name *

    Country *

    Upload file: We support .xls, .xlsx and .csv files under 4MB

    CHOOSE FILE

    Please submit your BOM List or Input the part online

    SUBMIT INFORMATION

    The STM32F427ZGT6 is a high-performance microcontroller based on the Arm® Cortex®-M4 32-bit RISC core, operating at frequencies up to 180 MHz. It integrates a floating-point unit (FPU) that supports all Arm® single-precision data processing instructions and data types, along with a complete set of DSP instructions and a Memory Protection Unit (MPU) to enhance application security.

    This microcontroller features high-speed embedded memory, including up to 2 MB of flash memory and 256+4 KB of SRAM, as well as backup SRAM of up to 4 KB. It connects to a series of enhanced I/O and peripherals via two APB buses, two AHB buses, and a 32-bit multi-AHB bus matrix.

    The STM32F427ZGT6 offers three 12-bit ADCs, two DACs, a low-power RTC, and twelve general-purpose 16-bit timers, including two PWM timers for motor control and two general-purpose 32-bit timers. It also provides a range of standard and advanced communication interfaces, such as I2C, USART/UART, SPI, SAI (serial audio interface), CAN (Controller Area Network), and SDIO.

    In terms of packaging, the STM32F427ZGT6 is typically available in a LQFP-144 package, making it suitable for a wide range of control and processing applications. Its high performance and flexibility have made it a popular choice in various fields, including consumer electronics, industrial automation, medical equipment, aerospace, and military applications.

    Overall, the STM32F427ZGT6 is a versatile and powerful microcontroller that combines high performance with a rich feature set, making it an ideal solution for a wide range of embedded systems and applications.
