SN74LVC8T245PWR

Manufacturer Part Number: SN74LVC8T245PWR Manufacturer / Brand: TI
Part of Description: Translation - Voltage Levels 8-Bit Dual-Supply Bus Xcvr Lead Free Status / RoHS Status: 16-bit Microcontrollers - MCU MCU 3/5V 56K Pb-free 64-QFP
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS
Datasheets:

Product parameters

ManufacturerTI
DetailsRoHS
Mounting StyleSMD/SMT
Package / CaseTSSOP-24
Minimum Operating Temperature– 40 C
Maximum Operating Temperature+85 C
PackagingReel
Moisture SensitiveYes
FeaturesPartial power down (Ioff), Over-voltage tolerant inputs, Output enable
Factory Pack Quantity2000
SubcategoryLogic ICs
Output Type3-State
Product TypeTranslation – Voltage Levels
Unit Weight0.003157 oz

Get in touch with us now

    Please submit your BOM List or Input the part online

    Please complete all required fields with your contact information.Click "SUBMIT REQUEST" we will contact you shortly by email. Or Email us: Sales001@easyiee.com

    First name *

    Last name *

    Company Email *

    Phone number *

    Company name *

    Country *

    Upload file: We support .xls, .xlsx and .csv files under 4MB

    CHOOSE FILE

    Please submit your BOM List or Input the part online

    SUBMIT INFORMATION

    The SN74LVC8T245PWR is an 8-bit dual-supply bus transceiver with configurable voltage translation and 3-state outputs manufactured by Texas Instruments (TI). This device is optimized to operate with two independent and configurable power supply rails, VCCA and VCCB, which can be set within a range of 1.65V to 5.5V. The A port is designed to track VCCA, while the B port tracks VCCB.

    The SN74LVC8T245PWR features a bidirectional data path, allowing for asynchronous communication between two data buses. It provides a non-inverting transmission of data, meaning that the data input at one port is directly transmitted to the corresponding output at the other port without any inversion.

    The transceiver has a tri-state output, which means that it can be placed in a high-impedance state in addition to the normal low and high states. This feature allows multiple devices to share a common data bus without causing conflicts.

    Additionally, the SN74LVC8T245PWR offers enhanced electrostatic discharge (ESD) protection, which exceeds the standards set by JESD 22. This makes the device more robust and reliable in harsh environments.

    The device is packaged in a 24-pin TSSOP (Thin Shrink Small Outline Package), which is a surface-mount package that provides a compact and robust solution for board-level integration.

    Overall, the SN74LVC8T245PWR is a versatile and reliable 8-bit dual-supply bus transceiver that is suitable for a wide range of applications, including industrial automation, telecommunication systems, and computing peripherals, where it provides efficient and reliable data communication between different voltage domains.
