LTM4628IV#PBF

Manufacturer Part Number: LTM4628IV#PBF Manufacturer / Brand: ADI
Part of Description: Switching Voltage Regulators 2x 8A or 1x 16A DC/DC uModule Reg Lead Free Status / RoHS Status: 16-bit Microcontrollers - MCU MCU 3/5V 56K Pb-free 64-QFP
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS
Datasheets:

Product parameters

ManufacturerADI
DetailsRoHS
Mounting StyleSMD/SMT
Package / CaseLGA-144
Minimum Operating Temperature– 40 C
Maximum Operating Temperature+125 C
PackagingTray
Moisture SensitiveYes
Product TypeSwitching Voltage Regulators
Factory Pack Quantity119
SubcategoryPMIC – Power Management ICs

Get in touch with us now

    Please submit your BOM List or Input the part online

    Please complete all required fields with your contact information.Click "SUBMIT REQUEST" we will contact you shortly by email. Or Email us: Sales001@easyiee.com

    First name *

    Last name *

    Company Email *

    Phone number *

    Company name *

    Country *

    Upload file: We support .xls, .xlsx and .csv files under 4MB

    CHOOSE FILE

    Please submit your BOM List or Input the part online

    SUBMIT INFORMATION

    The LTM4628IV#PBF is a complete dual 8A output switching mode DC/DC power supply that can be easily configured to provide a single 2-phase 16A output. This power module is designed for high efficiency and delivers 8A continuous current for each output. It operates within an input voltage range of 4.5V to 26.5V and supports two outputs, each with an output voltage range of 0.6V to 5.5V, which is set by a single external resistor.

    The LTM4628IV#PBF package includes the switching controller, power FETs, inductor, and all supporting components, making it a standalone solution that requires only a few input and output capacitors. It features a high switching frequency and a current mode architecture, which enables a very fast transient response to line and load changes without sacrificing stability.

    This power module supports frequency synchronization, multi-phase operation, burst mode operation, and output voltage tracking for supply rail sequencing. It also includes fault protection features such as overvoltage and overcurrent protection. The LTM4628IV#PBF has an onboard temperature diode for device temperature monitoring and supports soft-start/voltage tracking.

    The power module is offered in space-saving and thermally enhanced 15mm x 15mm x 4.32mm LGA and 15mm x 15mm x 4.92mm BGA packages. It is RoHS compliant with Pb-free finish and is suitable for a wide range of applications, including telecom and networking equipment, storage and ATCA cards, and industrial equipment.

    In summary, the LTM4628IV#PBF is a versatile and high-performance DC/DC power supply that offers dual 8A or single 16A output options, a wide input voltage range, and a range of advanced features that make it ideal for a variety of applications.
