IRFR3710ZTRPBF

Manufacturer Part Number: IRFR3710ZTRPBF Manufacturer / Brand: Infineon
Part of Description: MOSFETs MOSFT 100V 56A 18mOhm 69nC Qg Lead Free Status / RoHS Status: 16-bit Microcontrollers - MCU MCU 3/5V 56K Pb-free 64-QFP
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS
Datasheets:

Product parameters

ManufacturerInfineon
DetailsRoHS
Mounting StyleSMD/SMT
Package / CaseDPAK-3 (TO-252-3)
Minimum Operating Temperature– 55 C
Transistor Polarity+175 C
PackagingReel
Moisture SensitiveYes
ConfigurationSingle
Factory Pack Quantity2000
SubcategoryTransistors
Transistor Type1 N-Channel
Width6.22 mm
Unit Weight0.011640 oz

Get in touch with us now

    Please submit your BOM List or Input the part online

    Please complete all required fields with your contact information.Click "SUBMIT REQUEST" we will contact you shortly by email. Or Email us: Sales001@easyiee.com

    First name *

    Last name *

    Company Email *

    Phone number *

    Company name *

    Country *

    Upload file: We support .xls, .xlsx and .csv files under 4MB

    CHOOSE FILE

    Please submit your BOM List or Input the part online

    SUBMIT INFORMATION

    The IRFR3710ZTRPBF is an N-channel power MOSFET from Infineon Technologies, specifically designed for high-power applications. It features a robust construction and excellent electrical performance, making it suitable for a wide range of electronic systems.

    Key Features:

    • High Voltage Rating: The IRFR3710ZTRPBF has a maximum drain-to-source voltage (Vds) of 100V, allowing it to handle high-voltage loads effectively.
    • High Current Handling Capability: With a maximum continuous drain current (Ids) of 42A (or 56A depending on specific sources and conditions), this MOSFET can deliver significant power to the load.
    • Low RDS(on): The RDS(on) value, which represents the on-state resistance of the MOSFET, is typically 0.015 ohms (or 18mΩ @ 10V Vgs, according to some specifications). This low RDS(on) contributes to high efficiency and low power loss.
    • Fast Switching Speed: The IRFR3710ZTRPBF offers fast switching speeds, with rise and fall times typically measured in nanoseconds. This enables it to switch quickly between on and off states, reducing switching losses and improving overall efficiency.
    • Enhanced Thermal Management: With a maximum operating temperature of 175°C, the IRFR3710ZTRPBF can operate reliably in high-temperature environments. Its package design also aids in thermal dissipation, ensuring stable performance under demanding conditions.
    • RoHS Compliance: The IRFR3710ZTRPBF is compliant with RoHS standards, meaning it does not contain any hazardous substances that are restricted by these standards.

    Applications:

    • Power Management: The IRFR3710ZTRPBF is ideal for power management systems, where it can be used to control and regulate power flow efficiently.
    • LED Lighting: Its high current handling capability and low RDS(on) make it suitable for driving LED lighting systems, ensuring bright and stable illumination.
    • Electric Vehicles (EVs): The MOSFET can be used in EVs for battery management and motor control, contributing to the vehicle’s overall efficiency and performance.
    • Industrial Controls: The IRFR3710ZTRPBF is also suitable for industrial control systems, where it can be used to switch high-power loads reliably and efficiently.

    Package and Dimensions:

    The IRFR3710ZTRPBF is packaged in a TO-252-3 surface-mount package, which provides a compact and reliable footprint for high-power applications. Its dimensions are 6.73mm in length, 6.22mm in width, and 2.39mm in height, allowing it to fit into a variety of electronic systems with limited space constraints.

    In summary, the IRFR3710ZTRPBF is a high-performance N-channel power MOSFET that offers a combination of high voltage rating, high current handling capability, low RDS(on), and fast switching speed. Its robust construction and excellent electrical performance make it suitable for a wide range of high-power applications, including power management, LED lighting, electric vehicles, and industrial controls.
