G5Q-1A4-DC12

The G5Q-1A4-DC12 is a compact and high-performance electromechanical relay manufactured by Omron, designed for general-purpose applications. Here are its key features:

1. Relay Type:
   • This model is a single pole single throw normally open (SPST-NO) relay, making it suitable for switching a single circuit.
2. Coil Voltage:
   • The G5Q-1A4-DC12 operates on a 12 V DC coil voltage, ideal for integration with 12 V systems.
3. Contact Rating:
   • It has a high contact capacity, rated for 16 A at 250 V AC, making it suitable for controlling high-current devices like motors, lighting, and heating systems.
4. Compact Design:
   • The relay is designed with a compact form factor, ideal for space-limited applications while maintaining robust performance.
5. Dielectric Strength:
   • It offers high dielectric strength of 4,000 V between coil and contacts, ensuring safe electrical isolation and preventing interference.
6. Applications:
   • The G5Q-1A4-DC12 is commonly used in household appliances, HVAC systems, industrial equipment, and office automation.
7. Mounting Type:
   • It is designed for PCB mounting, making it easy to integrate into circuit designs.

The G5Q-1A4-DC12 relay is a reliable solution for high-current switching needs in a variety of general-purpose applications, combining compact size with high switching capacity.
