ADM2682EBRIZ

Manufacturer Part Number: ADM2682EBRIZ Manufacturer / Brand: ADI
Part of Description: RS-422/RS-485 Interface IC 16Mbps, 5 kV rms Signal & Power Isolated RS-485 Transceiver with 15 kV ESD Protection Lead Free Status / RoHS Status: 16-bit Microcontrollers - MCU MCU 3/5V 56K Pb-free 64-QFP
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS
Datasheets:

Product parameters

ManufacturerADI
DetailsRoHS
Mounting StyleSMD/SMT
Package / CaseSOIC-16
Minimum Operating Temperature– 40 C
Maximum Operating Temperature+85 C
PackagingTube
Moisture SensitiveYes
Number of Channels1 Channel
Factory Pack Quantity37
Product TypeRS-422/RS-485 Interface IC
Data Rate16 Mb/s
TypeRS-485 Isolated Transceiver
Unit Weight0.023492 oz

Get in touch with us now

    Please submit your BOM List or Input the part online

    Please complete all required fields with your contact information.Click "SUBMIT REQUEST" we will contact you shortly by email. Or Email us: Sales001@easyiee.com

    First name *

    Last name *

    Company Email *

    Phone number *

    Company name *

    Country *

    Upload file: We support .xls, .xlsx and .csv files under 4MB

    CHOOSE FILE

    Please submit your BOM List or Input the part online

    SUBMIT INFORMATION

    The ADM2682EBRIZ is a fully integrated 5 kV rms signal and power isolated data transceiver with ±15 kV ESD protection, designed for high-speed communication on multipoint transmission lines. It incorporates ADI’s proprietary iCoupler® technology, which integrates a 3-channel isolator, a tri-state differential line driver, a differential input receiver, and a converter into a single package. This transceiver is suitable for applications such as isolated RS-485/RS-422 interfaces, industrial field networks, and multipoint data transmission systems.

    The ADM2682EBRIZ operates with a single 5 V or 3.3 V power supply and features an active-high driver enable and an active-low receiver enable, which allows the receiver output to enter a high impedance state when disabled. It also includes current limiting and thermal shutdown features to protect against output short circuits and excessive power dissipation.

    With its high integration and compact SOIC-16 package, the ADM2682EBRIZ offers a high level of creepage and clearance, making it suitable for industrial applications. Additionally, it complies with ANSI/TIA/EIA-485-A and ISO 8482:1987(E) standards, ensuring reliable and robust communication performance.

    Overall, the ADM2682EBRIZ is a versatile and reliable data transceiver that combines signal and power isolation, high-speed communication, and robust ESD protection to cater to the needs of modern industrial and embedded systems applications.
