AD7795BRUZ-REEL

The AD7795BRUZ-REEL is a precision, 24-bit, sigma-delta (Σ-Δ) analog-to-digital converter (ADC) from Analog Devices. It offers a high-resolution measurement solution for low-frequency signals in industrial, process control, and precision instrumentation applications.

The AD7795BRUZ-REEL features a fully differential input with programmable gain amplifiers (PGAs) that provide flexibility in setting the input range. The ADC supports both unipolar and bipolar input signals and offers excellent linearity and accuracy.

The device integrates a low-noise, low-drift internal reference and a programmable digital filter that allows the user to optimize noise performance and conversion rate for specific applications. The ADC also provides a serial interface that supports SPI, QSPI, MICROWIRE, and DSPI communication protocols, making it easy to interface with microcontrollers and other digital systems.

The AD7795BRUZ-REEL is packaged in a small, RoHS-compliant, 16-lead, surface-mount LFCSP package that is suitable for high-density, board-space-constrained applications. The “-REEL” suffix indicates that the component is tape and reel packaged, which is convenient for automated assembly processes.

In summary, the AD7795BRUZ-REEL is a high-performance, precision ADC that offers a high-resolution solution for measuring low-frequency signals in a wide range of industrial and instrumentation applications. Its programmable gain amplifiers, internal reference, and digital filter provide flexibility and ease of use, while its small package size and tape and reel packaging make it suitable for automated manufacturing processes.
