AD654JRZ-REEL7

Manufacturer Part Number: AD654JRZ-REEL7 Manufacturer / Brand: ADI
Part of Description: Voltage to Frequency & Frequency to Voltage IC, LOW COST V/F CONV IC Lead Free Status / RoHS Status: 16-bit Microcontrollers - MCU MCU 3/5V 56K Pb-free 64-QFP
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS
Datasheets:

Product parameters

ManufacturerADI
DetailsRoHS
Mounting StyleSMD/SMT
Package / CaseSOIC-8
Minimum Operating Temperature– 40 C
Maximum Operating Temperature+85 C
PackagingReel
Moisture SensitiveYes
Product TypeVoltage to Frequency & Frequency to Voltage
Factory Pack Quantity750
SubcategoryData Converter ICs
Length5 mm
Width4 mm
Unit Weight0.019048 oz

Get in touch with us now

    Please submit your BOM List or Input the part online

    Please complete all required fields with your contact information.Click "SUBMIT REQUEST" we will contact you shortly by email. Or Email us: Sales001@easyiee.com

    First name *

    Last name *

    Company Email *

    Phone number *

    Company name *

    Country *

    Upload file: We support .xls, .xlsx and .csv files under 4MB

    CHOOSE FILE

    Please submit your BOM List or Input the part online

    SUBMIT INFORMATION

    The AD654JRZ-REEL7 is a high-performance, monolithic V/F (voltage-to-frequency) converter designed for a wide range of applications. It consists of an input amplifier, a precision oscillator system, and a high-current output stage. This converter allows for the setting of any full-scale (FS) frequency up to 500 kHz and any FS input voltage up to ±30 V with a simple RC network.

    At a full-scale frequency of 250 kHz, the AD654JRZ-REEL7 exhibits a linear error of only 0.03%, ensuring a high dynamic range of 80 dB. The overall temperature coefficient, excluding the influence of external components, is typically ±50 ppm/°C. The device operates from a single supply voltage ranging from 5 V to 36 V, with a low static current consumption of only 2.0 mA.

    The input amplifier of the AD654JRZ-REEL7 features low drift (typically 4 µV/°C) and can directly handle small signals from sources such as thermocouples or strain gauges, while providing a high input impedance of 250 MΩ. Unlike most V/F converters, the AD654JRZ-REEL7 offers square wave outputs, capable of driving up to 12 TTL loads, optocouplers, long cables, or similar loads.

    The AD654JRZ-REEL7 is packaged in a compact SOIC-8 form factor, making it suitable for integration into high-density circuit boards. Its low cost, low power consumption, and multifunctional input amplifier (supporting positive or negative voltage modes, negative current mode, and high input impedance with low drift) make it an ideal choice for various applications requiring precise voltage-to-frequency conversion.

    Overall, the AD654JRZ-REEL7 combines high performance, compact packaging, and versatility to meet the demands of modern electronic systems and applications.
