SPC560B50L3C6E0Y

The S9KEAZN32AMLCR is a 32-bit microcontroller from NXP’s Kinetis E series, designed for low-power, high-performance applications. It integrates a range of features suitable for automotive, industrial, and consumer electronics, providing a balance of processing capability and power efficiency.

Key Features:

• Core:
  • CPU: Features a 32-bit ARM Cortex-M0+ core, operating at up to 48 MHz, delivering efficient processing power for real-time applications.
  • Architecture: ARM Cortex-M0+ provides a good balance of performance and low power consumption, ideal for embedded systems.
• Memory:
  • Flash Memory: Includes 32 KB of Flash memory for storing application code and data.
  • SRAM: Equipped with 4 KB of SRAM for fast, volatile data storage.
  • EEPROM: Includes 2 KB of EEPROM for non-volatile storage of configuration and calibration data.
• Peripherals:
  • Analog:
    • ADC: 12-bit Analog-to-Digital Converter (ADC) for high-resolution analog signal processing.
  • Communication Interfaces:
    • UART: Serial communication interface for asynchronous data transfer.
    • SPI: Serial Peripheral Interface for high-speed data transfer.
    • I²C: Inter-Integrated Circuit interface for communication with peripheral devices.
  • Timers and PWM:
    • Timers: Includes multiple timers for precise timekeeping and event management.
    • PWM: Pulse Width Modulation channels for motor control and signal generation.
  • Others:
    • GPIO: General-purpose input/output pins for interfacing with external devices.
    • Watchdog Timer: Provides fault detection and recovery mechanisms.
• Power Management:
  • Low Power Modes: Designed with various power-saving modes to extend battery life and reduce power consumption.
  • Operating Voltage: Supports a wide voltage range, making it versatile for different power supply configurations.
• Package:
  • Package Type: Available in a 32-pin LQFP (Low-profile Quad Flat Package) or similar package options, offering a compact and robust solution for embedded systems.

Applications:

• Automotive: Suitable for automotive control systems, including body control modules and infotainment systems.
• Industrial: Ideal for industrial automation, sensor interfaces, and control systems.
• Consumer Electronics: Useful in consumer devices requiring efficient processing and low power consumption, such as wearable technology and smart home devices.

The S9KEAZN32AMLCR microcontroller provides a powerful yet efficient 32-bit ARM Cortex-M0+ core, ample memory, and a comprehensive set of peripherals, making it well-suited for a variety of embedded applications in automotive, industrial, and consumer electronics.
