MKL17Z64VFM4

The MKL17Z64VFM4 is a versatile microcontroller from NXP’s Kinetis L series, designed for applications requiring low power consumption and efficient processing. Here’s a detailed description of its features and specifications:

Core:

• ARM Cortex-M0+: 32-bit processor core operating at up to 48 MHz, offering low power and efficient performance for various embedded applications.

Memory:

• Flash Memory: 64 KB of internal Flash memory for program storage, suitable for small to medium-sized applications.
• SRAM: 16 KB of SRAM for fast data access and temporary storage.

Peripherals:

• Connectivity:
  • UART: Universal Asynchronous Receiver/Transmitter for serial communication.
  • SPI: Serial Peripheral Interface for high-speed data transfer.
  • I²C: Inter-Integrated Circuit interface for communication with peripheral devices.
• Timers and PWM:
  • Timers: Includes multiple 16-bit timers for event timing and control.
  • PWM: Pulse Width Modulation channels for motor control and signal generation.
• Analog Interfaces:
  • ADC: 12-bit Analog-to-Digital Converter (ADC) with up to 12 channels for analog signal input.
  • DAC: 12-bit Digital-to-Analog Converter (DAC) for generating analog output signals.
• Other Peripherals:
  • GPIO: General-purpose input/output pins for interfacing with external devices.
  • RTC: Real-Time Clock for maintaining accurate timekeeping.

Power Management:

• Low Power Modes: Various low-power modes including sleep and stop modes to minimize power consumption in battery-operated and energy-sensitive applications.
• Operating Voltage: Operates over a supply voltage range of 1.71V to 3.6V, making it suitable for low-power designs.

Package:

• Package Type: Available in a 48-pin LQFP (Low-profile Quad Flat Package), which offers a compact and manageable footprint for integration into various systems.

Development and Debugging:

• Debugging Interfaces: Supports standard debugging interfaces including SWD (Serial Wire Debug) for development and troubleshooting.

Applications:

• Consumer Electronics: Ideal for use in a wide range of consumer electronics and appliances requiring efficient processing and low power consumption.
• Industrial Control: Suitable for industrial control systems and automation tasks with its versatile peripheral set.
• Medical Devices: Can be used in medical devices needing reliable performance and low power operation.

The MKL17Z64VFM4 microcontroller combines efficient processing, ample memory, and a comprehensive set of peripherals in a compact package, making it well-suited for various low-power and embedded applications.
