Manufacturer Part Number: 1SS319 Manufacturer / Brand: Toshiba
Part of Description: SoC 1SS319 Lead Free Status / RoHS Status: table_img Lead free / RoHS Compliant
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS

Product parameters

Package / CaseSOT-24-4
Mounting StyleSMD/SMT
Maximum Operating Temperature0C
Minimum Operating Temperature+125 C
Factory Pack Quantity3000
Moisture SensitiveYes
If – Forward Current100 mA
Vf – Forward Voltage600 mV
Pd – Power Dissipation150 mW
Unit Weight0.000459 oz

Get in touch with us now

    Please submit your BOM List or Input the part online

    Please complete all required fields with your contact information.Click "SUBMIT REQUEST" we will contact you shortly by email. Or Email us: Sales001@easyiee.com

    First name *

    Last name *

    Company Email *

    Phone number *

    Company name *

    Country *

    Upload file: We support .xls, .xlsx and .csv files under 4MB


    Please submit your BOM List or Input the part online


    1SS319 Applications:

    Rectification in Power Supplies: Schottky diodes, including the 1SS319, are often used for rectification in power supply circuits. Their low forward voltage drop and fast switching characteristics make them suitable for converting alternating current (AC) to direct current (DC) in power supplies.

    Reverse Polarity Protection: Schottky diodes are used to provide reverse polarity protection in electronic circuits. Placing the diode in series with the power supply ensures that the current flows in the correct direction and prevents damage due to reverse polarity.

    Flyback Diode in Inductive Loads: In circuits with inductive loads such as relays, solenoids, and motors, the 1SS319 can be used as a flyback diode. It provides a path for the inductive current to circulate when the load is switched off, protecting other components from voltage spikes.

    Voltage Clamping: Schottky diodes are used for voltage clamping applications to limit the voltage across a specific component or part of the circuit. This helps protect sensitive components from excessive voltages.

    Signal Demodulation: Schottky diodes can be used for demodulating signals in communication circuits. They are employed in amplitude demodulators to recover the original signal from its modulated form.

    High-Frequency Applications: The fast switching speed of Schottky diodes makes them suitable for high-frequency applications such as RF (radio frequency) circuits, mixers, and detectors.

    Clipping and Clamping Circuits: Schottky diodes are used in clipping and clamping circuits to limit signal amplitudes or shift the DC level of signals.

    Logic Gates: Schottky diodes are used in the design of logic gates, especially in ECL (emitter-coupled logic) circuits, where their fast switching speed is advantageous.
